Sapphire RX 580 2048SP OC 8 GB
- GPU Name: Polaris 20
- GPU Variant: Polaris 20 XTX (215-0910052)
- Architecture: GCN 4.0
- Foundry: GlobalFoundries
- Process Size: 14 nm
- Transistors: 5,700 million
- Density: 24.6M / mm²
- Die Size: 232 mm²
- Chip Package: BGA-1401
- DirectX: 12 (12_0)
- OpenGL: 4.6
- OpenCL: 2.1
- Vulkan: 1.3
- Shader Model: 6.7
- Release Date: Oct 15th, 2018
- Generation: Polaris (RX 500)
- Predecessor: Arctic Islands
- Successor: Vega
- Production: Active
- Bus Interface: PCIe 3.0 x16
- Slot Width: Dual-slot
- Length: 170 mm (6.7 inches)
- TDP: 150 W
- Suggested PSU: 450 W
- Outputs:
- 1x DVI
- 2x HDMI 2.0b
- 2x DisplayPort 1.4a
- Power Connectors: 1x 8-pin
- Board Number: C940, D000
- Base Clock: 1168 MHz
- Boost Clock: 1306 MHz (+2%)
- Memory Clock: 1750 MHz – 7 Gbps effective
- Shading Units: 2048
- TMUs: 128
- ROPs: 32
- Compute Units: 32
- L1 Cache: 16 KB (per CU)
- L2 Cache: 2 MB
- Memory Size: 8 GB
- Memory Type: GDDR5
- Memory Bus: 256 bit
- Bandwidth: 224.0 GB/s
- Pixel Rate: 41.79 GPixel/s
- Texture Rate: 167.2 GTexel/s
- FP16 (half): 5.349 TFLOPS (1:1)
- FP32 (float): 5.349 TFLOPS
- FP64 (double): 334.3 GFLOPS (1:16)
