Comprehensive hardware architecture and silicon specification dossier for the HP OEM NVIDIA Quadro K4000 3 GB graphics accelerator (HP Spare 713381-001 / Assy 700104-001), detailing GK106GL Kepler 28nm silicon, 768 CUDA cores, 3 GB GDDR5 on a 192-bit bus (134.4 GB/s), PassMark G3D Mark of 2,718, and deployment in the Dell Precision T7610 workstation.

AMD Radeon Instinct MI50 32GB GPU Name: Vega 20 GL Architecture: GCN 5.1 (7 nm TSMC FinFET) Transistors: 13,230 million Die Size: 331 mm² Stream Processors: 3,840 Compute Units: 60 TMUs: 240 ROPs: 64 Core Clock: 1200 MHz Boost Clock: 1746 MHz Memory Size: 32 GB HBM2 Memory Bus: 4096-bit Bandwidth: 1.02 TB/s TDP: 300 W PassMark G3D Mark: 13,571 (Rank #188) Museum Inventory: 1 unit, added active turbine blower cooler, installed in Supermicro X8DAH Dual Xeon Workstation.

Gigabyte GeForce GTS 250 512MB (GV-N250-512I) GPU Name: G92B (G92-428-B1) Architecture: Tesla 2.0 (55 nm TSMC) Transistors: 754 million Die Size: 260 mm² CUDA Cores: 128 TMUs: 64 ROPs: 16 Core Clock: 675 MHz Shader Clock: 1620 MHz Memory Size: 512 MB Memory Type: GDDR3 Memory Bus: 256-bit Bandwidth: 64.0 GB/s TDP: 150 W PassMark G3D Mark: 563 (Rank #1,801) Museum Inventory: 1 unit, single cooler, standalone collection exhibit (bench-tested).

VGA GPU Cirrus Logic CL-GD510 | CL-GD520 Known as “Eagle II”, the CL-GD510 / CL-GD520 chipset arrived in 1988 as the successor to their first SVGA chipset, the CL-GD410/420. It fixed most of the CGA compatibility issues of its forebear. Some had a faster core clock that ran at 40 MHz while others had the 32 MHz version. Released: 1988 Bus: ISA 8-bit Chipset: Cirrus Logic CL-GD510 / 520 Standards: MDA, Hercules, CGA, EGA, VGA Memory: 256 KB DRAM (80,…

14,923 – AMD Radeon Instinct MI60 (32 GB HBM2) 14,111 – MSI RTX 2060 Ventus 6G OC (6 GB GDDR6) 13,102 – NVIDIA GeForce RTX 3060 Laptop GPU (6 GB GDDR6) – Lenovo Legion 5 10,744 – MSI GeForce RTX 3050 LP 6G OC – Corsair Air 540 7,609 – Sapphire RX 580 2048SP OC 8 GB – Mac Pro Twelve Core 5,610 – MSI GTX 680 2GB Lightning 2,718 – HP NVIDIA Quadro K4000 3GB – Dell Precision T7610 2,175 – GIGABYTE GV-R777OC-1GD 563 – GIGABYTE GeForce GTS 250 512 MB 325 – NVIDIA GeForce GT 120 Mac Edition 283 – ATI Radeon HD 2600 XT Mac Edition 166 – ASUS ATI Radeon HD 4350 164 – NVIDIA GeForce 8600M GT 128 – MAC NVIDIA GeForce 7300 GT 69 – Sapphire ATI Radeon X1600 PRO 38 – ASUS EAX300SE 37 – NVIDIA GeForce 6200 8 – nVIDIA GeForce FX5200

MSI RTX 2060 Ventus 6G OC (MS-V375) Video Adapter: NVIDIA GeForce RTX 2060 (6 GB) Video Adapter: MSI RTX 2060 Ventus 6G OC (MS-V375) BIOS Version: 90.06.46.00.1B BIOS Date: 11/3/2019 GPU Code Name: TU106-200A Transistors: 10600 million Process Technology: 12 nm Die Size 445 mm2 Bus Type: PCI Express 3.0 x16 @ 1.1 x16 Bus Type: GDDR6 (Samsung) Bus Width: 192-bit Bandwidth: 19.0 GB/s Architecture: nVIDIA Turing Core Clocks: Boost: 1710 MHz CUDA® CORES: 1920 Units Memory Speed: 14 Gbps…

Comprehensive hardware architecture dossier and empirical telemetry for the MSI GeForce RTX 3050 LP 6G OC graphics card. Powered by NVIDIA GA107 Ampere silicon (8nm, 2,304 CUDA cores, 72 Tensor cores, 18 RT cores, 6 GB GDDR6 96-bit). Features 70W TDP slot-powered operation, low-profile dual-slot form factor, verified PCIe 3.0 x8 negotiation, Resizable BAR support up to 8GB, and Linux nouveau driver telemetry in the Corsair Carbide Series Air 540 “Cube” workstation.
