MB

Comprehensive technical specification and architectural dossier for the Supermicro X9SRi-F server motherboard. Details Intel C602 chipset, Socket R (LGA 2011), Quad-Channel DDR3 support up to 256GB, PCIe 3.0 lane allocation, SATA 3.0/2.0 topology, and dedicated IPMI 2.0 remote management. Verified physical unit (PCB Rev 1.20, S/N: ZM14BS021242, AMI BIOS 3.3, IPMI BMC 3.64) actively deployed in Corsair Carbide Air 540 workstation.

MB MSI 845PE Max MS-6580 ver 2.0 CPU support: Socket 478 for Intel® Pentium 4/Celeron processors Celeron (Willamette) – 1.5 GHz – 2 GHz Celeron (Northwood) – 1.5 GHz – 2.8 GHz Celeron D – 2.13 GHz – 3.2 GHz Pentium 4 – 1.4 GHz – 3.4 GHz Pentium 4 Extreme Edition – 3.2 GHz – 3.4 GHz Core Frequency from 1.4 GHz to 2.8 GHz and up*not tested Chipsets Intel® 845PE chipsets AGP 4x slot (1.5v only) Support 100/133/166…
