Intel Core Ultra 5 225T Processor (Arrow Lake-S, TSMC 3nm N3B, Socket LGA 1851). 10 Cores / 10 Threads (6 Lion Cove P-Cores up to 4.90 GHz + 4 Skymont E-Cores up to 4.40 GHz), 20 MB Smart Cache, 22 MB L2 Cache, Dual-Channel DDR5-6400, Intel AI Boost NPU 3 (13 TOPS), Intel Arc Xe-LPG Graphics, 35W Base TDP (114W PL2). PassMark CPU Mark: 25,900. Installed in HP ProDesk 4 Mini G1i AI Black.

AMD Radeon Instinct MI50 32GB GPU Name: Vega 20 GL Architecture: GCN 5.1 (7 nm TSMC FinFET) Transistors: 13,230 million Die Size: 331 mm² Stream Processors: 3,840 Compute Units: 60 TMUs: 240 ROPs: 64 Core Clock: 1200 MHz Boost Clock: 1746 MHz Memory Size: 32 GB HBM2 Memory Bus: 4096-bit Bandwidth: 1.02 TB/s TDP: 300 W PassMark G3D Mark: 13,571 (Rank #188) Museum Inventory: 1 unit, added active turbine blower cooler, installed in Supermicro X8DAH Dual Xeon Workstation.

Gigabyte GeForce GTS 250 512MB (GV-N250-512I) GPU Name: G92B (G92-428-B1) Architecture: Tesla 2.0 (55 nm TSMC) Transistors: 754 million Die Size: 260 mm² CUDA Cores: 128 TMUs: 64 ROPs: 16 Core Clock: 675 MHz Shader Clock: 1620 MHz Memory Size: 512 MB Memory Type: GDDR3 Memory Bus: 256-bit Bandwidth: 64.0 GB/s TDP: 150 W PassMark G3D Mark: 563 (Rank #1,801) Museum Inventory: 1 unit, single cooler, standalone collection exhibit (bench-tested).

Dell Precision T7610 Flagship Dual-Socket Workstation (CZ-BRN-NEU). Dual Intel Xeon E5-2637 v2 (8C/16T total, 3.50 GHz base / 3.80 GHz turbo, 30 MB L3 cache, 130W TDP), 64 GB SK hynix DDR3-1333 Registered ECC memory (expandable to 512 GB across 16 DIMMs), NVIDIA GeForce GTS 250 (512 MB GDDR3), integrated LSI 2308 6Gb/s SAS/SATA controller, dual Intel Gigabit LAN, and 1300W Gold modular power supply.

Intel Xeon Processor E5-2637 v2 (Ivy Bridge-EP, 22 nm, Socket LGA 2011). 4 Cores / 8 Threads at 3.50 GHz (3.80 GHz Turbo), 15 MB Smart Cache, Quad-Channel DDR3-1866, 130W TDP, and dual 8.00 GT/s QPI links. PassMark CPU Mark: 6,483 (Single Thread: 1,939). Museum collection holds 2 units (SR1B7 / M1 stepping) installed in Dell Precision 7610.

Intel Xeon Processor E5-2680 (Sandy Bridge-EP, 32 nm, Socket LGA 2011). 8 Cores / 16 Threads at 2.70 GHz (3.50 GHz Turbo), 20 MB Smart Cache, Quad-Channel DDR3, 130W TDP, and dual 8.00 GT/s QPI links. PassMark CPU Mark: 9,284. Museum collection holds 4 units (SR0KH / C2 stepping; 1 active in Corsair Air 540 “Cube”, 3 archive).

Comprehensive technical specification and architectural dossier for the Supermicro X9SRi-F server motherboard. Details Intel C602 chipset, Socket R (LGA 2011), Quad-Channel DDR3 support up to 256GB, PCIe 3.0 lane allocation, SATA 3.0/2.0 topology, and dedicated IPMI 2.0 remote management. Verified physical unit (PCB Rev 1.20, S/N: ZM14BS021242, AMI BIOS 3.3, IPMI BMC 3.64) actively deployed in Corsair Carbide Air 540 workstation.

Comprehensive hardware architecture dossier and operational workstation report for the Corsair Carbide Series Air 540 High Airflow ATX Cube Case (CC-9011030-WW). Documents the revolutionary dual-chamber Direct Airflow Path layout, full specifications, cooling and expansion capabilities, and active deployment housing the “Cube” workstation with a Supermicro X9SRi-F motherboard, Intel Xeon E5-2680 processor, 160 GB Quad-Channel ECC memory, MSI RTX 3050 LP GPU, and Kingston HyperX 3K SSD with empirical thermal telemetry.

Bitmain Antminer D3 19.3G Key Hardware Specifications Launch Date: 2017 (Batch / Date Code: Week 45, 2017 – 1745) Manufacturer: Bitmain Technologies Ltd. Algorithm: X11 (Proof of Work for Dash) Hashrate: 19.3 GH/s (±5% at stock 537 MHz) Power Consumption: ~1,350 W (±10% at wall @ 25°C with APW3++ PSU) Power Efficiency: ~0.070 J/MH at stock; up to 0.045 J/MH with undervolt firmware Hash Boards: 3 × D3_DashBoard_V2.2 ASIC Chip: Bitmain BM1760 60 × BM1760 X11 ASICs per board =…

Supermicro X8DAH Dual Xeon Workstation Report Type: System Diagnostic & Hardware Inventory • Target Host: supermicro (192.168.xxx.xxx) • Site: CZ-BRN-NEU Verification Date: August 24, 2026 1. System Summary & Computer Overview Category Property Value Computer Computer Type ACPI x64-based Multi-Processor Server / Workstation Hostname supermicro System Vendor Supermicro Product Model X8DAH (Version: 1234567890) Motherboard Supermicro X8DAH Motherboard MAC 04:ed:33:c3:5e:5b (Wi-Fi) / 00:25:90:e6:21:4a (LAN1) Operating System OS Distribution Debian GNU/Linux 13 (Trixie) x86_64 Kernel Release Linux 6.12.101+deb13-amd64 (#1 SMP PREEMPT_DYNAMIC) Compiler…
