QNAP TS-469L
- QTS 4.3.4.0644 -> 4.3.4.2814 (2025.10.22)
- Hardware Specifications
- CPU: Intel® Atom™ 2.13 GHz Dual-core Processor
- DRAM: 2 x 2GB (3000 MB usable)
- Flash Memory: 512MB DOM
- Hard Disk Drive: Hard Disk Drive 4 x 3.5” or 2.5” SATA 3Gb/s hard drive or SSD
- Hard Disk Tray: 4 x Hot-swappable tray
- HDD1:
- HDD2:
- HDD3:
- HDD4:
- LAN Port: 2 x Gigabit RJ-45 Ethernet port
- LED Indicators: Status, LAN, USB, eSATA, Power, HDD 1, HDD 2, HDD 3, HDD 4
- USB:
- 2 x USB 3.2 Gen 1 port (Back: 2)
- 5x USB 2.0 port (Front: 1; Back: 4)
- Support USB printer, pen drive, USB hub, and USB UPS etc.
- eSATA: 2 x eSATA port (Back)
- Buttons: System: Power button, USB One-Touch-Backup Button, Reset button
- Alarm Buzzer: System warning
- Form Factor: Tower
- Dimensions:
- 177 (H) x 180 (W) x 235 (D) mm
- 6.97 (H) x 7.09 (W) x 9.25 (D) inch
- Weight: Net weight: 3.65 kg (8.04 lbs)
- Gross weight: 4.65 kg (10.24 lbs)
- Sound Level (dB):
- HDD sleep: 13.7 dB
- In operation: 22.4 dB (with 4 x 500GB HDDs installed)
- Power Consumption (W):
- Sleep mode: 25W
- In Operation:43W – (with 4 x 500GB HDD installed)
- Power-off (in WOL mode): 1W
- Temperature: 0-40˚C
- Humidity: 5~95% RH non-condensing, wet bulb: 27˚C.
- Power Supply: Input: 100-240V AC, 50/60Hz, Output: 250W
- Secure Design: K-lock security slot for theft prevention
- VGA: Reserved VGA interface for maintenance
- HDMI™: v1.3
- IR Receiver: Compatible with either QNAP RM-IR001 or MCE remote controls
- Fan: 1 x quiet cooling fan (9 cm, 12V DC)
